Product Advantages & Benefits
Soft, Transparent Design: The loading catheter’s soft, transparent construction and smooth tip allow easy embryo loading, clear observation, and gentle insertion, reducing patient discomfort and the risk of embryo damage.
Ergonomic Steel Cover Handle: The steel cover at the catheter tail provides a secure, easy-to-grip handle, enhancing control and precision during the transfer procedure.
Dual Sterile Packaging: Loading and guiding catheters are individually packaged in separate sterile packs, ensuring sterility and eliminating cross-contamination risks.
Multiple Configurations: Choose from straight echogenic or curved oval-head guiding catheters, plus an eco-tip variant, to match different patient anatomies and clinical preferences.
Enhanced Visibility: The echogenic design of the straight guiding catheter improves visibility under ultrasound, supporting accurate placement and reducing procedural errors.
Customizable with Cannulas: Optional cannulas (diameter 1.3mm, length 203mm) allow reshaping of the guiding catheter, offering flexibility to adapt to complex cases.
Product Specifications
Name | Ref. Code | Type | Specifications | Pack Size |
|---|
Embryo Transfer Catheter | ETCA23175 | Normal Type | Outer tube diameter 2.3mm, Overall catheter length 175mm | 10 pcs/box |
Embryo Transfer Catheter | ETCB20175 | Oval Head Type | Outer tube diameter 2.0mm, Overall catheter length 175mm | 10 pcs/box |
Embryo Transfer Catheter | ETCB20175-ET | Eco-Tip Type | Outer tube diameter 2.0mm, Overall catheter length 175mm | 10 pcs/box |
Cannula | C20130 | Accessory | Diameter 1.3mm, total length 203mm | 10 pcs/box |
Applications
IVF (In Vitro Fertilization) clinics
Embryo transfer procedures
Assisted reproductive technology (ART) centers
Reproductive medicine practices
FAQ
Q: What is the difference between normal type and oval head type?
A: The normal type (ETCA23175) features a straight, echogenic guiding catheter for enhanced ultrasound visibility. The oval head type (ETCB20175) has a curved design with an oval head, suitable for navigating more anatomically complex cervical canals.
Q: Why are the loading and guiding catheters packaged separately?
A: Separate sterile packaging ensures each component remains uncontaminated until use, reducing infection risks and maintaining the highest clinical safety standards.
Q: What is the Eco-Tip variant for?
A: The Eco-Tip design is optimized for atraumatic embryo delivery, further minimizing the risk of embryo damage during transfer, making it ideal for delicate cases.
Q: Can the cannula be used with any of the catheters?
A: Yes, the optional cannula (C20130) is designed to reshape the guiding catheter, offering flexibility for different procedural requirements across all models.
